Crown XLS 1502

Two-channel, 525W @ 4Ω Power Amplifier


Out of stock

Notify Me when back in stock

The CROWN XLS 1502 is Two-channel, 525W @ 4Ω Power Amplifier with higher DSP capabilities: More control; has band pass filter per channel.

CROWN XLS 1502 Features:

  • Class D amp with Crown’s ultra-efficient DriveCore technology weighs less than 11 lb
  • Higher DSP capabilities: More control; has band pass filter per channel
  • Increased lighting functionality; turn off all LED indicators except clip and thermal to reduce distraction in dark venues
  • Selectable input sensitivity; 1.4Vrms and 0.775Vrms options so that amp can be driven at full power
  • Set sleep mode after specified time without having to press a button
  • Security setting disables menu buttons; menu locked/unlocked by entering combination
  • System reset allows factory settings to be restored
  • Remote power trigger
  • Peakx™ Limiters provide maximum output while protecting your speakers
  • XLR, 1/4″, RCA inputs provide flexibility
  • Integrated PureBand™ Crossover System for better performance and control
  • Efficient forced-air fans prevent excessive thermal build-up
GTIN: 691991001000 SKU: PRS-XLS-1502 Categories: , , ,

Meet the new XLS DriveCore™ 2 Series

The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4Ω bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.



TypePower Amplifier
Number of Channels2
Amplifier ClassClass D
Channel TypeDual Channel
Maximum Power Output525 W
Impedance4 ohms
Signal-to-noise Ratio103 db
Dimension (Wx H x D)272 x 483 x 89 mm
Weight3.9 kg


ModeXLS 1502
Frequency Response+0dB, -1dB
Signal to Noise>103dB (at .775Vrms, 6dB lower)
Intermodulation Distortion< 0.3%
Damping Factor> 200
THD< 0.5%
CrosstalkAt 1kHz: > 85dB, At 20kHz: > 55dB
Dimensions19" (48.3 cm) x 3.5" (8.9 cm) x 7.7" (19.6 cm)
Weight8.6 lbs (3.9 kgs)
