Yamaha DM3S 22-Channel Digital Mixer

Original price was: ₹195,100.00.Current price is: ₹145,000.00.

Out of stock

Notify Me when back in stock

The Yamaha DM3S 22-Channel Digital Mixer. The portable Yamaha DM3 Standard compact digital mixing console features versatile capabilities that make it perfect for a wide range of applications. The DM3 Standard offers superb sound quality, fast and easy setup and operation, and professional-level features. The Yamaha DM3S is a versatile 22-channel digital mixing console designed for a wide range of applications, from live performances and recording studios to broadcast and corporate events. Compact and portable, the DM3S offers exceptional sound quality, user-friendly operation, and professional-grade features that cater to both novice and experienced users

DM3S Key Features:

  • 8 + 1 fader configuration
  • 9-inch multi-touch screen
  • Input mixing channels: 16 mono + 1 stereo + 2 FX return
  • Busses: 1 Stereo, 6 Mix, 2 FX, 2 Matrix (Supports Input to Matrix)
  • Local I/O: 16 Mic/Line (12 XLR + 4 XLR/TRS Phones Combo) inputs, and 8 (XLR) outputs
  • USB: 18 inputs, and 18 outputs
  • 18 Effects, and GEQ on Mix 1-6 and Stereo channels
  • Sampling rate: 48kHz/96kHz
BrandYamaha
ModelDM3 Standard
Mixing Capacity
Input Channels16 mono + 1 stereo + 2 FX return
Mix Buses6
Matrices2 (Supports Input to Matrix)
Stereo Buses1
FX Buses2
Cue Buses1
General specifications (I/O Connectors)
Analog Input16 Mic/Line (12 XLR + 4 XLR/TRS Phones Combo)
Analog Output8 (XLR)
DanteNo
Network1 (RJ-45)
USB TO HOST1 (USB Type-B, USB2.0)
USB TO DEVICE1 (USB Type-A)
Phones1 (TRS Phones)
DC1 (XLR 4pin, DC power IN)
User Interface1x 9-inch multi-touch screen, 9x faders (8 channels + 1 main), 1x "Touch and Turn" rotary encoder
Recording & Playback
PC/MacRecording 18 track, Playback 18 track
USB storage deviceRecording 2 track (USB hard disk / SSD / flash memory), Playback 2 track (USB hard disk / SSD / flash memory)
Sampling frequency rate96 kHz / 48 kHz
Signal delayLess than 1.3 ms, (CH INPUT to OMNI OUT, Fs=96 kHz)
Frequency response+0.5, -1.0 dB 20 Hz-20 kHz, reference to the nominal output level@1 kHz, INPUT to OMNI OUT
Total harmonic distortionLess than 0.01 % 20 Hz - 20 kHz@+4 dBu into 10 kΩ, INPUT to OMNI OUT, Input Gain= Min*1
Hum & noise level
Equivalent input noise-126 dBu typ., Input Gain= Max.
Residual output noise-84 dBu, ST main off*2
Dynamic range110 dB typ., DA Converter, 106 dB typ., INPUT to OMNI OUT, Input Gain=Min.
Crosstalk-100 dB, adjacent INPUT/OMNI OUT channels, Input Gain= Min. @1 kHz*3
Power requirementsDC24 V/2.5 A, PA-L500 (100 V-240 V, 50 Hz/60 Hz)
Power consumption43 W
DimensionsW 320mm x H 140mm D 455mm
Net weight6.5 kg (14.3 lb)

Additional information

Brand

CHANNELS

22 Channels

Manufactured in

Warranty
