Studiomaster D.Mix 20 16 Channel Digital Mixer


Out of stock

Notify Me when back in stock

The Studiomaster D.Mix 20 16 Channel Digital Mixer with Touchscreen. The Studiomaster D.Mix 20 16 digital mixer combines the best of what an LCD touchscreen can offer a digital with an intuitive interface for speed and precision in live mixing scenarios.

D. Mix 20 Key Features:

  • 16 mono Input channels with assignable controls.
  • 8 Channels Inserts.
  • 2 Stereo input channels.
  • 1 USB audio channel.
  • Full duplex USB port (allows for simultaneous recording & reproduction) for the reproduction of digital audio data from a PC & recording mixing onto a PC..
  • 2 integrated DSP’s with EQ, Noise Gate, Compressor / Limiter & Delay.
  • 4 Aux Send outs & 4 Subgroup outs or 8 Aux outputs.
  • 6 DCA groups.
  • 100mm motor-driven fader.
  • 24 bits/48kHz sampling rate.
  • User-definable presets.
  • +48V Phantom power.
  • LCD touch screen for settings, routing, and navigation.
  • XLR & Jack Main outputs & Stereo Control Room output.
BrandStudiomaster Professional
Mixer TypeDigital Mixer
Channel16 Channel
Fader Type100mm motorized Fader
LCD touch screenYes
Gain (Mic/Line/Stereo Line)50dB / 50 dB
Max Gain (Mic/Line)70dB / 70 dB
Mic (Gain Min/Gain Max)0 dBu / -50 dBu
Line (Gain Min /Gain Max)+8 dBu / -40 dBu
Mic Input5K Balanced
Line input19K Unbalanced
Main Output level (Nominal / Max)0 dBu (0.775 V RMS) / +20 dBu (8V RMS)
Main Output Impedance120 Ω
Frequency Response20Hz to 20KHz (+0dB ± 1.5dB)
Total Harmonic Distortion<0.05%
Signal to Noise Ratio85dB
Mono Mic (Treble/Mid with Sweep/Bass)±24dB (21 Hz – 19.2 KHZ)
Stereo Line (Treble/Mid-Hi/Mid-low/Bass)±24dB (21 Hz – 19.2 KHZ)
EFX32 – Bit EFX Processor
Phantom Supply+48V
Dimensions (W x D x H) mm445 x 355 x 140
Net Weight (Kgs.)7.25
