Yamaha DM3 with Dante 22-Channel Digital Mixer
Original price was: ₹231,200.00.₹175,250.00Current price is: ₹175,250.00.
Only 1 left in stock
The Yamaha DM3 with Dante 22-Channel Digital Mixer. The Yamaha DM3 with Dante is an ultracompact 22-channel digital mixer that integrates Dante connectivity, offering high-quality sound and versatile functionality. It is designed for a wide range of applications, from live performances to studio recording, providing professional-level features in a compact form.
Yamaha DM3 Key Features
- 22 Channels: 16 analog inputs and 8 analog outputs.
- Dante Connectivity: Enables seamless integration with other Dante-enabled devices for flexible audio networking.
- High-Resolution Sound: Supports up to 96kHz sample rates for superior audio quality.
- 9-Inch Touch Screen: Intuitive touch interface for easy control and navigation.
- Dual Effects Processors: Includes high-quality multi-effects processors with 18 types of effects, such as REV HD and REV R3.
- QuickPro Presets™: Optimized presets for various microphones and output equipment, developed in collaboration with major manufacturers.
- Compact and Lightweight: Weighs only 6.5 kg, making it highly portable.
- DAW Remote Mode: Allows control of your digital audio workstation directly from the mixer.
- 6 Mix + 2 Matrix + 2 Effects Buses: Provides flexible routing options for complex setups.
- Scene Presets: Pre-configured settings for different applications to simplify setup
| Brand | Yamaha |
| Model | DM3-D |
| Mixing Capacity | |
| Input Channels | 16 mono + 1 stereo + 2 FX return |
| Mix Buses | 6 |
| Matrices | 2 (Supports Input to Matrix) |
| Stereo Buses | 1 |
| FX Buses | 2 |
| Cue Buses | 1 |
| General specifications (I/O Connectors) | |
| Analog Input | 16 Mic/Line (12 XLR + 4 XLR/TRS Phones Combo) |
| Dante | 2 (etherCON: Primary/Secondary) |
| Analog Output | 8 (XLR) |
| Dante | No |
| Network | 1 (RJ-45) |
| USB TO HOST | 1 (USB Type-B, USB2.0) |
| USB TO DEVICE | 1 (USB Type-A) |
| Phones | 1 (TRS Phones) |
| DC | 1 (XLR 4pin, DC power IN) |
| User Interface | 1x 9-inch multi-touch screen, 9x faders (8 channels + 1 main), 1x "Touch and Turn" rotary encoder |
| Recording & Playback | |
| PC/Mac | Recording 18 track, Playback 18 track |
| USB storage device | Recording 2 track (USB hard disk / SSD / flash memory), Playback 2 track (USB hard disk / SSD / flash memory) |
| Sampling frequency rate | 96 kHz / 48 kHz |
| Signal delay | Less than 1.3 ms, (CH INPUT to OMNI OUT, Fs=96 kHz) |
| Frequency response | +0.5, -1.0 dB 20 Hz-20 kHz, reference to the nominal output level@1 kHz, INPUT to OMNI OUT |
| Total harmonic distortion | Less than 0.01 % 20 Hz - 20 kHz@+4 dBu into 10 kΩ, INPUT to OMNI OUT, Input Gain= Min*1 |
| Hum & noise level | |
| Equivalent input noise | -126 dBu typ., Input Gain= Max. |
| Residual output noise | -84 dBu, ST main off*2 |
| Dynamic range | 110 dB typ., DA Converter, 106 dB typ., INPUT to OMNI OUT, Input Gain=Min. |
| Crosstalk | -100 dB, adjacent INPUT/OMNI OUT channels, Input Gain= Min. @1 kHz*3 |
| Power requirements | DC24 V/2.5 A, PA-L500 (100 V-240 V, 50 Hz/60 Hz) |
| Power consumption | 43 W |
| Dimensions | W 320mm x H 140mm D 455mm |
| Net weight | 6.5 kg (14.3 lb) |
